Quantity:
Item: 10.100.096.03/40 - 100mm flat Natural Rubber suction cup with cleats
| |
Item#: 10.100.096.03/40
Price: $31.97 ea.
|
100mm flat Natural Rubber suction cup with cleats
General Specifications
Style: Flat
Cleats: Yes
Material: Natural Rubber
Thread Size: None
Outside Diameter: 100.0mm
Weight(lbs): 0.149
Color: Brown
Lifting Capacity: See Chart [X] CloseLifting Capacity for Item 10.100.096.03/40
| Level of Vacuum (inHg) |
Horizontal |
Vertical |
| 6"Hg |
14.60 lbs. |
7.30 lbs. |
| 18"Hg |
43.82 lbs. |
21.91 lbs. |
| 27"Hg |
65.73 lbs. |
32.86 lbs. |
***Disclaimer: Lifting capacity for handling a non-porous surface. Figures are theoretical and based on 80% of suction cup outside diameter with a 2:1 safety margin for horizontal lifting and a 4:1 safety margin for vertical lifting.
Includes fitting?: NO
 Recommended replacement for: 102.100.269.4 |
|
|
|
Material Specifications
| Material name |
Wear Resistance |
Oil |
Weather & Ozone |
Temperature Range |
| Natural Rubber |
Good |
Poor |
Poor |
-40 to 176 °F (-40 to 80 °C) |
Video of Product in Action
No Videos Available for: 10.100.096.03/40
Related CAD files of Product
Dimensional drawing for Item: 10.100.096.03/40
Click on the image to enlarge
Parts and accessories for Suction Cup: 10.100.096.03/40
No parts or accessories related to this item were found.
